Factory DIY CNC 6090 Mini Metal CNC Milling Machine

Factory DIY CNC 6090 Mini Metal CNC Milling Machine

Categories: ,

$3,200.00

Specifications
Compare

Description

Buy Factory DIY CNC 6090 Mini Metal CNC Milling Machine – ONLINE

Description
Overview
Quick Details
Condition:
New
Range of Spindle Speed(r.p.m):
1 – 24000 rpm
Positioning Accuracy (mm):
0.02 mm
No. of Spindles:
Single
Working Table Size(mm):
600×900
Machine Type:
CNC Router
Travel (X Axis)(mm):
600 mm
Travel (Y Axis)(mm):
900 mm
Repeatability (X/Y/Z) (mm):
0.02 mm
Spindle Motor Power(kW):
2.2
CNC or Not:
Brand Name:
BLUE ELEPHANT
Voltage:
220V,1 PH,50/60HZ
Dimension(L*W*H):
1300*1100*1000
Certification:
CE
Weight (KG):
250
Control System Brand:
Mach3
Warranty:
1 Year
After-sales Service Provided:
Online support
Key Selling Points:
Multifunctional
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Marketing Type:
New Product 2020
Machinery Test Report:
Provided
Warranty of core components:
1 Year
Core Components:
Motor, Pump
Effective Working area:
600*900*160mm
Spindle:
2.2kw water cooling spindle
Motor and driver:
Leadshine M542 Stepper driver
Inverter:
2.2kw Fuling inverter
Working Voltage:
220V 1phase, 50Hz
Tool sensor:
Simple Tool sensor
Table surface:
T-slot working table with pvc

Products Description

Feature
This is a new type of classic mini CNC router. It can meet the production process of signage in the advertising industry, engraving and cutting of two-color plates, and engraving of Plexiglas and wood boards. In addition, this machine is also the first choice for small businesses and home use.
mini cnc milling machine for metal
Parameters
Description
Parameter
Effective Working area
600*900*160mm
Spindle
2.2kw water cooling spindle
Motor and driver
Leadshine M542 Stepper driver
Inverter
2.2kw Fuling inverter
Working Voltage
220V 1phase, 50Hz
Tool sensor
Simple Tool sensor
Table surface
T-slot working table

Sample & Application

WoodFurniture Industry: Wave Plate, fine pattern, antique furniture, wooden door, screen, craft sash, composite gates,cupboarddoors, interior doors, sofa legs, headboards and so on.

Advertising Industry: advertising identification, sigh making, Acrylic engraving and cutting, crystal word making,blaster molding,and other advertising materials derivatives making.
Die Industry:A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand,plastic sheeting,PVCpipe, wooden planks and other non-metallic mold.
Relief Sculpture and 3D Engraving & Cylindrical object.
Mini cnc milling machine for metal

Packing&Shipping

mini cnc milling machine for metal
Packaging Details
1.The innermost layer is EPE pearl cotton film package.
2.The middle layer is wrapping up with environmental protection material .
3.And the outermost layer is winding up with PE stretch film.
4.They’re very environmentally friendly.
5.If you need a wooden box, we will make a wooden box.
